1.Electrical system: with colorful LCD display, with self-test, monitoring, emergency fault alarm, human-computer interaction and good, high-profile electrical control software, higher reliability.
2.Power system: advanced turbocharged engine exhaust enough power reserves, it is possible to maximize the power of the engine to achieve the perfect match, reducing power losses.
3.Hydraulic system: imported international brands hydraulic parts, power loss, fast action, complex motor coordination, high efficiency and energy saving, reliability and long service life.
4.Walking System: use heavier type front and rear drive axle, gearbox, providing higher carrying capacity.
5.Cab: new style cab, new interior design, vision, bright and spacious, humane front gear mechanism, adjustable suspension seat with a high-grade, silicone shock absorption, superior driving environment.
6.Cooling system: parallel cooling installation, installation and removal are easy to clean; it has very high cooling efficiency.
| operating weight | 6600kg |
| Bucket volume | 0.28CBM |
| Engine power | 55kw |
| total length | 5796mm |
| total width | 2150mm |
| total height | 2827mm |
| boom length | 3050mm |
| arm length | 1750mm |
| wheel base | 2400mm |
| Max.travel speed | 30km/h |
| max digging distance | 6074mm |
| ground max digging distance | 5878mm |
| max digging depth | 3228mm |
| max digging height | 6202mm |
| max dumping height | 4533mm |
| minimum swing radius | 2361mm |
| Climbing ability | 25 |
| dozer blade width | 2024mm |
| dozer blade height | 440mm |
| hydraulic oil tank | 103L |
| fuel tank | 125L |
| arm digging force | 15KN |
| bucket digging force | 25KN |
